Get started with APIs

TODO

  • Skip tidyverse, re-integrate schemas?

️✅ Learning objectives

  • Fetch json-formatted data from the web.
  • Parse nested lists with the {tidyverse}.
library(dplyr)
library(jsonlite)
library(purrr)
library(tibble)
library(tidyr)

Where can I find APIs?

API Directories

The APIs.guru API List

Fetch all APIs.guru APIs

all_apis <- jsonlite::fromJSON("https://api.apis.guru/v2/list.json")
length(all_apis)
#> [1] 2529
head(names(all_apis))
#> [1] "1forge.com"                    "1password.com:events"
#> [3] "1password.local:connect"       "6-dot-authentiqio.appspot.com"
#> [5] "ably.io:platform"              "ably.net:control"
purrr::pluck_depth(all_apis)
#> [1] 10
str(head(all_apis, 2), max.level = 2)
#> List of 2
#>  $ 1forge.com          :List of 3
#>   ..$ added    : chr "2017-05-30T08:34:14.000Z"
#>   ..$ preferred: chr "0.0.1"
#>   ..$ versions :List of 1
#>  $ 1password.com:events:List of 3
#>   ..$ added    : chr "2021-07-19T10:17:09.188Z"
#>   ..$ preferred: chr "1.0.0"
#>   ..$ versions :List of 1

Fetch JSON: Exercises

(not written yet, but general idea will be…)

  • Provide URLs of JSON-formatted data
    • How many top-level items are described in this data?
    • How deeply is this data nested?
    • What is the X of the Yth item?

Rectangling data

Unnesting

  • Is value a list of lists of observations?
    • tidyr::unnest_longer(value) separates into rows
  • Is value a list of lists of variables?
    • tidyr::unnest_wider(value) separates into columns
  • tidyr::unnest_auto() uses heuristic to choose between those

How does unnest_auto() choose?

flowchart TD
    B{{"How many elements have names?"}}
        B -->|"none"| C["Unnest longer, drop indices"]
        B -->|"some"| C
        B -->|"all"| D{{"Are any names reused?"}}
            D -->|"yes"| E["Unnest wider"]
            D -->|"no"| F["Unnest longer, keep indices"]

What does unnest_auto() miss? (1)

Column is a named list (not a list of named lists).

  • Error: Names are lost
  • Check: rlang::is_named(df$col)
  • Fix: dplyr::mutate(col_name = names(col)) before unnesting.

What does unnest_auto() miss? (2)

One or more elements of a list column are empty.

  • Error: Assumes unnest_longer(), even if it’s just some missing values among a column that is obviously otherwise unnest_wider-worthy.
  • Check: any(lengths(df$col) == 0)
  • Fix: Do the unnest_auto() checks only on values of col that have lengths(col) > 0

What does unnest_auto() miss? (3)

One or more elements of a list column lacks names, other elements have names.

  • Error: Names are lost.
  • Check: (flowchart already tests this, but makes the wrong decision)
  • Fix: unnest_longer(col, indices_to = "descriptive_name") as fall-through

How should I choose unnest direction?

flowchart TD
    A{{"Is the overall column named?"}}
        A -->|"yes"| AA["Create a names column"]
            AA --> B
        A -->|"no"| B
    B{{"How many non-empty elements have names?"}}
        B -->|"none"| C["Unnest longer, drop indices"]
        B -->|"some"| F
        B -->|"all"| D{{"Are any names reused?"}}
            D -->|"yes"| E["Unnest wider"]
            D -->|"no"| F["Unnest longer, keep indices"]

Rectangling APIs.guru’s list

enframe()

all_apis_df <- all_apis |>
  tibble::enframe(name = "api_name")
all_apis_df
#> # A tibble: 2,529 × 2
#>    api_name                      value
#>    <chr>                         <list>
#>  1 1forge.com                    <named list [3]>
#>  2 1password.com:events          <named list [3]>
#>  3 1password.local:connect       <named list [3]>
#>  4 6-dot-authentiqio.appspot.com <named list [3]>
#>  5 ably.io:platform              <named list [3]>
#>  6 ably.net:control              <named list [3]>
#>  7 abstractapi.com:geolocation   <named list [3]>
#>  8 adafruit.com                  <named list [3]>
#>  9 adobe.com:aem                 <named list [3]>
#> 10 adyen.com:AccountService      <named list [3]>
#> # ℹ 2,519 more rows

value column: Unnest wider or longer?

(incorporate flowchart once it exists)

rlang::is_named(all_apis_df$value)
#> [1] FALSE
non_empties <- all_apis_df$value[lengths(all_apis_df$value) > 0]
element_names <- purrr::map(non_empties, names)
has_null <- unique(purrr::map_lgl(element_names, is.null))
has_null
#> [1] FALSE
common_names <- purrr::reduce(element_names, intersect)
common_names
#> [1] "added"     "preferred" "versions"

Unnest values

all_apis_versions <- all_apis_df |>
  tidyr::unnest_wider(value)
all_apis_versions
#> # A tibble: 2,529 × 4
#>    api_name                      added                    preferred versions
#>    <chr>                         <chr>                    <chr>     <list>
#>  1 1forge.com                    2017-05-30T08:34:14.000Z 0.0.1     <named list>
#>  2 1password.com:events          2021-07-19T10:17:09.188Z 1.0.0     <named list>
#>  3 1password.local:connect       2021-04-16T15:56:45.939Z 1.5.7     <named list>
#>  4 6-dot-authentiqio.appspot.com 2017-03-15T14:45:58.000Z 6         <named list>
#>  5 ably.io:platform              2019-07-13T11:28:07.000Z 1.1.0     <named list>
#>  6 ably.net:control              2021-07-26T09:45:31.536Z 1.0.14    <named list>
#>  7 abstractapi.com:geolocation   2021-04-14T17:12:40.648Z 1.0.0     <named list>
#>  8 adafruit.com                  2018-02-10T10:41:43.000Z 2.0.0     <named list>
#>  9 adobe.com:aem                 2019-01-03T07:01:34.000Z 3.7.1-pr… <named list>
#> 10 adyen.com:AccountService      2023-02-17T11:02:20.620Z 6         <named list>
#> # ℹ 2,519 more rows

What if we went longer?

all_apis_df |>
  tidyr::unnest_longer(value)
#> # A tibble: 7,587 × 3
#>    api_name                      value            value_id
#>    <chr>                         <named list>     <chr>
#>  1 1forge.com                    <chr [1]>        added
#>  2 1forge.com                    <chr [1]>        preferred
#>  3 1forge.com                    <named list [1]> versions
#>  4 1password.com:events          <chr [1]>        added
#>  5 1password.com:events          <chr [1]>        preferred
#>  6 1password.com:events          <named list [1]> versions
#>  7 1password.local:connect       <chr [1]>        added
#>  8 1password.local:connect       <chr [1]>        preferred
#>  9 1password.local:connect       <named list [1]> versions
#> 10 6-dot-authentiqio.appspot.com <chr [1]>        added
#> # ℹ 7,577 more rows

choose_unnest_direction()

# Based on `tidyr::unnest_auto` and `tidyr:::guess_dir`
choose_unnest_direction <- function(df, col) {
  col <- tidyselect::vars_pull(dplyr::tbl_vars(df), {{col}})
  col_contents <- df[[col]]
  code <- character()

  if (rlang::is_named(col_contents)) {
    code <- c(
      code,
      glue::glue(
        "dplyr::mutate(descriptive_name = names({col}), .before = {col})"
      )
    )
  }

  non_empties <- col_contents[lengths(col_contents) > 0]

  element_names <- purrr::map(non_empties, names)
  has_null <- unique(purrr::map_lgl(element_names, is.null))
  if (identical(has_null, TRUE)) {
    code <- c(
      code,
      glue::glue("tidyr::unnest_longer({col}, indices_include = FALSE)")
    )
    return(glue::glue_collapse(code, sep = " |>\n  "))
  } else if (identical(has_null, FALSE)) {
    common_names <- purrr::reduce(element_names, intersect)
    n_common <- length(common_names)
    if (n_common > 0) {
      code <- c(
        code,
        glue::glue("tidyr::unnest_wider({col})")
      )
      return(glue::glue_collapse(code, sep = " |>\n  "))
    }
  }
  code <- c(
    code,
    glue::glue("tidyr::unnest_longer({col}, indices_to = \"descriptive_name\")")
  )
  return(glue::glue_collapse(code, sep = " |>\n  "))
}

Unnest versions: Wider or longer?

rlang::is_named(all_apis_versions$versions)
#> [1] FALSE
non_empties <- all_apis_versions$versions[lengths(all_apis_versions$versions) > 0]
element_names <- purrr::map(non_empties, names)
has_null <- unique(purrr::map_lgl(element_names, is.null))
has_null
#> [1] FALSE
common_names <- purrr::reduce(element_names, intersect)
common_names
#> character(0)
choose_unnest_direction(all_apis_versions, versions)
#> tidyr::unnest_longer(versions, indices_to = "descriptive_name")

Unnest versions

all_apis_longer <- all_apis_versions |>
  tidyr::unnest_longer(versions, indices_to = "version")
all_apis_longer
#> # A tibble: 3,992 × 5
#>    api_name                      added            preferred versions     version
#>    <chr>                         <chr>            <chr>     <named list> <chr>
#>  1 1forge.com                    2017-05-30T08:3… 0.0.1     <named list> 0.0.1
#>  2 1password.com:events          2021-07-19T10:1… 1.0.0     <named list> 1.0.0
#>  3 1password.local:connect       2021-04-16T15:5… 1.5.7     <named list> 1.5.7
#>  4 6-dot-authentiqio.appspot.com 2017-03-15T14:4… 6         <named list> 6
#>  5 ably.io:platform              2019-07-13T11:2… 1.1.0     <named list> 1.1.0
#>  6 ably.net:control              2021-07-26T09:4… 1.0.14    <named list> 1.0.14
#>  7 abstractapi.com:geolocation   2021-04-14T17:1… 1.0.0     <named list> 1.0.0
#>  8 adafruit.com                  2018-02-10T10:4… 2.0.0     <named list> 2.0.0
#>  9 adobe.com:aem                 2019-01-03T07:0… 3.7.1-pr… <named list> 3.7.1-…
#> 10 adyen.com:AccountService      2023-02-17T11:0… 6         <named list> 3
#> # ℹ 3,982 more rows

What if we went wider?

all_apis_versions |> head() |> tidyr::unnest_wider(versions)
#> # A tibble: 6 × 9
#>   api_name   added preferred `0.0.1`      `1.0.0`      `1.5.7`      `6`
#>   <chr>      <chr> <chr>     <list>       <list>       <list>       <list>
#> 1 1forge.com 2017… 0.0.1     <named list> <NULL>       <NULL>       <NULL>
#> 2 1password… 2021… 1.0.0     <NULL>       <named list> <NULL>       <NULL>
#> 3 1password… 2021… 1.5.7     <NULL>       <NULL>       <named list> <NULL>
#> 4 6-dot-aut… 2017… 6         <NULL>       <NULL>       <NULL>       <named list>
#> 5 ably.io:p… 2019… 1.1.0     <NULL>       <NULL>       <NULL>       <NULL>
#> 6 ably.net:… 2021… 1.0.14    <NULL>       <NULL>       <NULL>       <NULL>
#> # ℹ 2 more variables: `1.1.0` <list>, `1.0.14` <list>

Preferred versions

all_apis_preferred <- all_apis_longer |>
  dplyr::filter(preferred == version) |>
  dplyr::select(api_name, version, versions)
all_apis_preferred
#> # A tibble: 2,529 × 3
#>    api_name                      version     versions
#>    <chr>                         <chr>       <named list>
#>  1 1forge.com                    0.0.1       <named list [7]>
#>  2 1password.com:events          1.0.0       <named list [7]>
#>  3 1password.local:connect       1.5.7       <named list [7]>
#>  4 6-dot-authentiqio.appspot.com 6           <named list [7]>
#>  5 ably.io:platform              1.1.0       <named list [7]>
#>  6 ably.net:control              1.0.14      <named list [7]>
#>  7 abstractapi.com:geolocation   1.0.0       <named list [8]>
#>  8 adafruit.com                  2.0.0       <named list [7]>
#>  9 adobe.com:aem                 3.7.1-pre.0 <named list [7]>
#> 10 adyen.com:AccountService      6           <named list [7]>
#> # ℹ 2,519 more rows

Preferred versions: Wider or longer?

choose_unnest_direction(all_apis_preferred, versions)
#> dplyr::mutate(descriptive_name = names(versions), .before = versions) |>
#>   tidyr::unnest_wider(versions)
head(names(all_apis_preferred$versions))
#> [1] "0.0.1"  "1.0.0"  "1.5.7"  "6"      "1.1.0"  "1.0.14"
all_apis_preferred_wide <- all_apis_preferred |>
  tidyr::unnest_wider(versions)

Preferred versions unnested

all_apis_preferred_wide
#> # A tibble: 2,529 × 10
#>    api_name         version added info         updated swaggerUrl swaggerYamlUrl
#>    <chr>            <chr>   <chr> <list>       <chr>   <chr>      <chr>
#>  1 1forge.com       0.0.1   2017… <named list> 2017-0… https://a… https://api.a…
#>  2 1password.com:e… 1.0.0   2021… <named list> 2023-0… https://a… https://api.a…
#>  3 1password.local… 1.5.7   2021… <named list> 2023-0… https://a… https://api.a…
#>  4 6-dot-authentiq… 6       2017… <named list> 2021-0… https://a… https://api.a…
#>  5 ably.io:platform 1.1.0   2019… <named list> 2021-0… https://a… https://api.a…
#>  6 ably.net:control 1.0.14  2021… <named list> 2021-0… https://a… https://api.a…
#>  7 abstractapi.com… 1.0.0   2021… <named list> 2021-0… https://a… https://api.a…
#>  8 adafruit.com     2.0.0   2018… <named list> 2021-0… https://a… https://api.a…
#>  9 adobe.com:aem    3.7.1-… 2019… <named list> 2023-0… https://a… https://api.a…
#> 10 adyen.com:Accou… 6       2023… <named list> 2023-0… https://a… https://api.a…
#> # ℹ 2,519 more rows
#> # ℹ 3 more variables: openapiVer <chr>, link <chr>, externalDocs <list>

Preferred versions glimpse

dplyr::glimpse(all_apis_preferred_wide)
#> Rows: 2,529
#> Columns: 10
#> $ api_name       <chr> "1forge.com", "1password.com:events", "1password.local:…
#> $ version        <chr> "0.0.1", "1.0.0", "1.5.7", "6", "1.1.0", "1.0.14", "1.0…
#> $ added          <chr> "2017-05-30T08:34:14.000Z", "2021-07-19T10:17:09.188Z",…
#> $ info           <list> [["contact@1forge.com", "1Forge", "http://1forge.com"]…
#> $ updated        <chr> "2017-06-27T16:49:57.000Z", "2023-02-27T15:08:09.418Z",…
#> $ swaggerUrl     <chr> "https://api.apis.guru/v2/specs/1forge.com/0.0.1/swagge…
#> $ swaggerYamlUrl <chr> "https://api.apis.guru/v2/specs/1forge.com/0.0.1/swagge…
#> $ openapiVer     <chr> "2.0", "3.0.0", "3.0.2", "3.0.0", "3.0.1", "3.0.1", "3.…
#> $ link           <chr> "https://api.apis.guru/v2/specs/1forge.com/0.0.1.json",…
#> $ externalDocs   <list> <NULL>, <NULL>, <NULL>, <NULL>, <NULL>, <NULL>, ["API …

info: wider or longer?

choose_unnest_direction(all_apis_preferred_wide, info)
#> tidyr::unnest_wider(info)
all_apis_preferred_wide |>
  tidyr::unnest_wider(info, names_sep = "_")
#> # A tibble: 2,529 × 76
#>    api_name  version added info_contact info_description info_title info_version
#>    <chr>     <chr>   <chr> <list>       <chr>            <chr>      <chr>
#>  1 1forge.c… 0.0.1   2017… <named list> "Stock and Fore… 1Forge Fi… 0.0.1
#>  2 1passwor… 1.0.0   2021… <NULL>       "1Password Even… Events API 1.0.0
#>  3 1passwor… 1.5.7   2021… <named list> "REST API inter… 1Password… 1.5.7
#>  4 6-dot-au… 6       2017… <named list> "Strong authent… Authentiq… 6
#>  5 ably.io:… 1.1.0   2019… <named list> "The [REST API … Platform … 1.1.0
#>  6 ably.net… 1.0.14  2021… <named list> "Use the Contro… Control A… 1.0.14
#>  7 abstract… 1.0.0   2021… <NULL>       "Abstract IP ge… IP geoloc… 1.0.0
#>  8 adafruit… 2.0.0   2018… <NULL>       "### The Intern… Adafruit … 2.0.0
#>  9 adobe.co… 3.7.1-… 2019… <named list> "Swagger AEM is… Adobe Exp… 3.7.1-pre.0
#> 10 adyen.co… 6       2023… <named list> "This API is us… Account A… 6
#> # ℹ 2,519 more rows
#> # ℹ 69 more variables: `info_x-apisguru-categories` <list>,
#> #   `info_x-logo` <list>, `info_x-origin` <list>, `info_x-providerName` <chr>,
#> #   `info_x-serviceName` <chr>, info_license <list>, info_termsOfService <chr>,
#> #   `info_x-unofficialSpec` <lgl>, `info_x-preferred` <lgl>,
#> #   `info_x-publicVersion` <lgl>, `info_x-timestamp` <chr>,
#> #   `info_x-description-language` <chr>, `info_x-release-note` <list>, …

info: hoist()

all_preferred_apis_with_categories <- all_apis_preferred_wide |>
  tidyr::hoist(info, categories = "x-apisguru-categories")
all_preferred_apis_with_categories
#> # A tibble: 2,529 × 11
#>    api_name             version added categories info         updated swaggerUrl
#>    <chr>                <chr>   <chr> <list>     <list>       <chr>   <chr>
#>  1 1forge.com           0.0.1   2017… <chr [1]>  <named list> 2017-0… https://a…
#>  2 1password.com:events 1.0.0   2021… <chr [1]>  <named list> 2023-0… https://a…
#>  3 1password.local:con… 1.5.7   2021… <chr [1]>  <named list> 2023-0… https://a…
#>  4 6-dot-authentiqio.a… 6       2017… <chr [1]>  <named list> 2021-0… https://a…
#>  5 ably.io:platform     1.1.0   2019… <chr [1]>  <named list> 2021-0… https://a…
#>  6 ably.net:control     1.0.14  2021… <chr [1]>  <named list> 2021-0… https://a…
#>  7 abstractapi.com:geo… 1.0.0   2021… <chr [1]>  <named list> 2021-0… https://a…
#>  8 adafruit.com         2.0.0   2018… <chr [1]>  <named list> 2021-0… https://a…
#>  9 adobe.com:aem        3.7.1-… 2019… <chr [1]>  <named list> 2023-0… https://a…
#> 10 adyen.com:AccountSe… 6       2023… <chr [1]>  <named list> 2023-0… https://a…
#> # ℹ 2,519 more rows
#> # ℹ 4 more variables: swaggerYamlUrl <chr>, openapiVer <chr>, link <chr>,
#> #   externalDocs <list>

Filter APIs

all_apis_preferred_wide |>
  tidyr::hoist(info, categories = "x-apisguru-categories") |>
  dplyr::rowwise() |>
  dplyr::filter("open_data" %in% categories) |>
  dplyr::ungroup()
#> # A tibble: 318 × 11
#>    api_name             version added categories info         updated swaggerUrl
#>    <chr>                <chr>   <chr> <list>     <list>       <chr>   <chr>
#>  1 amentum.space:aviat… 1.5.0   2021… <chr [2]>  <named list> 2023-0… https://a…
#>  2 amentum.space:gravi… 1.1.1   2021… <chr [2]>  <named list> 2021-0… https://a…
#>  3 amentum.space:space… 1.1.2   2021… <chr [2]>  <named list> 2023-0… https://a…
#>  4 api.gov.uk:vehicle-… 1.1.0   2020… <chr [1]>  <named list> 2021-0… https://a…
#>  5 apis.guru            2.2.0   2015… <chr [2]>  <named list> 2023-0… https://a…
#>  6 apisetu.gov.in:aaha… 3.0.0   2021… <chr [1]>  <named list> 2021-0… https://a…
#>  7 apisetu.gov.in:acko  3.0.0   2021… <chr [1]>  <named list> 2021-0… https://a…
#>  8 apisetu.gov.in:agtr… 3.0.0   2021… <chr [1]>  <named list> 2021-0… https://a…
#>  9 apisetu.gov.in:ahar… 3.0.0   2021… <chr [1]>  <named list> 2021-0… https://a…
#> 10 apisetu.gov.in:aiim… 3.0.0   2021… <chr [1]>  <named list> 2021-0… https://a…
#> # ℹ 308 more rows
#> # ℹ 4 more variables: swaggerYamlUrl <chr>, openapiVer <chr>, link <chr>,
#> #   externalDocs <list>

Rectangling: Exercises

  • Provide sample (constructed) data, have you choose direction.
  • To include:
    • Simple longer.
    • Simple wider.
    • Overall column is named, otherwise nothing to unnest.
    • Overall column is named, then there’s stuff to unnest.
    • Empty values, otherwise clearly wider.
    • unnest_auto() goes wider, but shared names are coincidental.
    • Some elements unnamed, but definitely longer.

Survey

Please let me know what you think about this chapter!
